SANY Road Machinery Grader SMG180C-6 180hp Motor Grader

  • >=1 Units
    $65,000.00
Model Number:
SMG180C-6
Weight:
14600kg
Lead Time:
Quantity(Units) 1 - 1 >1
Est. Time(days) 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
Forward Speed(km/h):
44.4
Reverse Speed(km/h):
35
Warranty:
1 Year
After-sales Service Provided:
Overseas service center available, Engineers available to service machinery overseas, Overseas third-party support available
Condition:
New
Place of Origin:
Hunan, China
Brand Name:
SANY
Dimension(L*W*H):
8558*2540*3214 mm
Certification:
CE, ISO
Product name:
SANY Road Grader SMG180C-6 180hp Motor Grader
Supplier:
Dongfeng Cumins
Emission standard:
Euro III
Model:
QSB6.7-C170
Rated power:
129 kW
Rated rotation speed:
2200 rpm
Peak torque:
800 Nm
Length of blade:
3660 mm standard configuration
Height of blade:
620 mm
Tilt angle:
90°
Supply Ability
Supply Ability:
30 Unit/Units per Month
Packaging & Delivery
Packaging Details
SANY Road Grader SMG180C-6 180hp Motor Grader
Nude packing/RORO
Port
Shanghai, Qingdao and etc.
Lead Time :
Quantity(Units) 1 - 1 >1
Est. Time(days) 30 To be negotiated
Video Description








SANY Road Machinery Grader SMG180C-6 180hp Motor Grader

Product Description
Rated power: 129/2200kW/RPM
Max.torque: 800N.m
Operating weight (standard): 14600kg
Direct drive power shift transmission

Specifications:
Power System Spec.
Supplier
Dongfeng Cumins
Emission standard
Euro Ⅲ
Model
QSB6.7-C170
Rated power
129 kW
Rated rotation speed
2200 rpm
Peak torque
800 Nm
Dimensions
Typical: L*W*H
8558×2540×3214 mm
With front counterweight and rear scarifier: L*W*H
10068×2540×3214 mm
With front bulldozing plate and rear scarifier: L*W*H
10758×2740×3214 mm
Front and rear axle base
6088 mm
Middle and rear wheel base
1538 mm
Clearance from rear axle to ground
370 mm
Load Spec.
Weight of typical type
14600 Kg
Max. total weight (with front bulldozing plate and rear scarifier)
17000 Kg
Max.traction
90 KN
Operating Device Spec.
Length of blade
3660 mm standard configuration
Height of blade
620 mm
Tilt angle
90°
Turning angle
360°
Running Spec.
Gears
8 forward and 6 reverse
Forward speed
4.2/5.7/8.3/11.4/17.9/24.4/33.7/44.4 km/h
Reverse speed
3.3/6.2/9.0/14.1/26.4/35.0 km/h
Steering angle of front wheel
Left 50°, right 50°
Tilt angle of front wheel
Left 17°, right 17°
Articulated steering angle
Left 20°, right 20°
Oscillation angle of front axle
Up 16°, down 16°
Min. turning radius
7.3 m
Model of tire
4.0-24-16PR standard configuration
Tank Capacity
Max. capacity of hydraulic oil tank
92 L
Max. capacity of fuel tank
300 L
