SHANTUI Official SR12-5 12 Ton Hydraulic Single Drum Vibratory Construction Machine Road Roller for Sale

FOB Reference Price:Get Latest Price
$22,000.00 - $49,000.00 / Units | 1 Unit/Units (Min. Order)
Static Linear Pressure:
325N/cm
Model Number:
SR12-5
Engine:
105kW
Lead Time:
Quantity(Units) 1 - 1 >1
Est. Time(days) 25 Negotiable
Report Suspicious Activity
Overview
Quick Details
Power(W):
105kw
Travel Speed:
0-9.6km/h
After-sales Service Provided:
Free spare parts, Video technical support, Online support, Field installation, commissioning and training, Field maintenance and repair service
Warranty:
1 Year
Applicable Industries:
Hotels, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Construction works
Condition:
New
Type:
Single Drum Roller
Grade Ability:
30%
Place of Origin:
Shandong, China
Brand Name:
SHANTUI
Dimension(L*W*H):
6021*2402*3127 mm
Weight:
12300 kg
Certification:
CE/ISO9001
Hydraulic Pump Brand:
Imported
Hydraulic Valve Brand:
Imported
Engine Brand:
Weichai
Product name:
Road Roller
Color:
Yellow
Rated power:
105kW
Rated speed:
2000r/min
Compaction width:
2140mm
Front wheel weight:
7100 kg
Static linear load:
325/378 N/cm
High vibration amplitude:
1.8
Low vibration amplitude:
1.0
Vibration frequency (high/low):
33/30 Hz
Supply Ability
Supply Ability:
100 Unit/Units per Month road roller
Packaging & Delivery
Packaging Details
Nude package ---- Container&RORO
Port
Shanghai
Picture Example:
package-img
package-img
Lead Time :
Quantity(Units) 1 - 1 >1
Est. Time(days) 25 To be negotiated
Video Description






SHANTUI Official SR12-5 12 Ton Hydraulic Single Drum Vibratory Construction Machine Road Roller for Sale

Product Description
 Technical Features

1. Featuring prominent performances, high reliability, good fuel economy, and strong power, Weichai WP6G140E22 engine maintains the machine under best compacting status to guarantee the construction quality.



2. Shantui’s patented new vibratory drum features more excellent structure and stability performances. The super-high lubricating oil capacity guarantees the good lubrication and cooling for the vibra.



3. The vibratory pumps and vibratory motors adopt international renowned brand products to guarantee the reliability and compacting performance of the vibration system.



4. The single gearshift joystick can effectively improve the working efficiency of the operator and relieve the fatigue.



5. The imported comfortable and firm seat is equipped with the retractable seat belt and rubber shock-absorbing design to remarkably reduce the working strength.



6. The cab is equipped with air conditioning system and the rubber damper design to isolate the operator from the vibration source to remarkably relieve the working strength.



7. The double traveling drive system provides power to the front drum and rear axle to achieve outstanding control performance and traction force for the whole machine.



8. Two speeds are at your choice, of which the low speed is suitable for vibratory compacting operation and climbing and the high speed can realize rapid transfer and large-range movement of the machine.



9. Standard double-amplitude function expands the application scope of the equipment.



10. The high span between high and low centrifugal forces helps the establishment of compacting power system schemes for different density specifications.



11. The design of the drum vibration parameters conforms to the requirements of working site and the padfoot drum can be assembled to expand the application scope.



12. Large angle openable hood, 8-point central pressure measuring system, maintenance-free battery, real-time monitoring of pressures and temperatures, and reasonable arrangement of diesel and working oil tanks enable Shantui roller to realize excellent maintenance performance, shorten the shutdown time, and improve the utilization rate of whole machine.

Length × width × height (mm)6021×2402×3127 6021×2362×3127Total weight (kg)12300/13450
Front wheel weight (kg)7100/8250Theoretical gradeability (%)48
Vibratory drum width (mm)2140Static linear load (N/cm)325/378
High vibration amplitude1.8/1.4Low vibration amplitude1.0/0.78
Vibration frequency (high/low) (Hz)33/30Centrifugal force (high/low) (kN)270/180
Engine modelWeichai WP6G140E22Rated power105
Number/height of padfoot (mm)154/95



Photos:
