cheap price mining equipment mobile rock stone crusher machine jaw crusher for sale

FOB Reference Price:Get Latest Price
$18,900.00 - $21,000.00 / Units | 1 Unit/Units (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Jaw Crusher
Application:
Stone
Motor Type:
AC Motor
Power(W):
45-55
Capacity(t/h):
40-100
Place of Origin:
Shanghai, China
Brand Name:
Oriemac
Model Number:
PE500*750
Dimension(L*W*H):
2035*1921*2000mm
Weight:
11200kg
Certification:
ISO9001:2008
Product name:
jaw crusher
Feed Opening Size:
500*750mm
Max. Feeding Size:
425mm
Adjustable Range of Output Size:
50-100mm
After-sales Service Provided:
No overseas service provided
Warranty:
12 Months
Supply Ability
Supply Ability:
10 Unit/Units per Week
Packaging & Delivery
Packaging Details
Nude packing
Port
Shanghai
Lead Time :
15 days after deposit

cheap price mining equipment mobile rock stone crusher machine jaw crusher for sale

Product Description

Usage and Application:

The jaw crusher is widely used in mining, building materials, chemical industry, metallurgy and so on. It is suitable for primary and secondary crushing all kinds of minerals and rocks with compressive strength less than 320 MPa



Working Principle:

The belt and belt pulley is driven by a motor, and the movable jaw moves up and down via eccentric shaft. The angle between fixed jaw and movable jaw becomes smaller when the moving jaw runs down, then the materials are crushed into pieces. It becomes bigger when the movable jaw runs up. The movable jaw plate leaves the fixed jaw plate under the action of tension rod and spring, then the end products come out from the crushing cavity.



1. Simple structure, convenient maintenance;
2. High crushing ratio, even output granularity;
3. High reliability, low investment;
4. Low noise, less dust
